CX1030
CHENXU
| Emission/Emisión排放 | Euro-Ⅲ |
| Cabin/Cabina车身 | single cabin 1760mm width |
| Wheel base/Distancia ontro ojps(mm)轴距 | 2860 |
| overall size(mm)/外观尺寸 | 5540*1920*2300 |
| Cargo Box Size(mm)/货箱内尺寸 | 3700*1750*400 |
| Wheel track (front/rear)（mm）轮距 | 1535/1485 |
| Curb Weight（Kg）/整备质量 | 2320 |
| rated payload (Kg)/额定载质量 | 3500 |
| G.VW/总重量 | 5320 |
| Max. gradeability(°)/最大爬坡度 | 30% |
| front axle payload/前桥吨位 | 2T |
| Rear axle后桥吨位/Main reduction ratio主减速比 | 3.5T/4.875 |
| Tyre size/轮胎尺寸 | 6+1/6.50R16 |
| Brake system/制动系统 | Hydraulic brake/Air brake |
| Parking brake/驻车制动 | Central drum type |
| gearbox/变速箱 | 5MT |
| Capacity of fuel tank（L）/油箱容积 | 80L |
| battery/ 电池 | 12V |
| Engine model/发动机型号 | JE493ZLQ3A(ISUZU） |
| Displacement/Cilindrad a(cc)排量 | 2771 |
| Power/Potencia(KW)/发动机功率 | 75/3600 |
| Torque/Par(N.m)发动机扭矩 | 240/2000 |
| seat material/座椅材质 | fabric |
| power steering/助力转向 | ● |
| media/媒体 | MP5 with reverse camera |
| A/C空调 | ● |
| power window/电动车窗 | ● |
| Central lock/中控锁 | ● |
| Emission/Emisión排放 | Euro-Ⅲ |
| Cabin/Cabina车身 | single cabin 1760mm width |
| Wheel base/Distancia ontro ojps(mm)轴距 | 2860 |
| overall size(mm)/外观尺寸 | 5540*1920*2300 |
| Cargo Box Size(mm)/货箱内尺寸 | 3700*1750*400 |
| Wheel track (front/rear)（mm）轮距 | 1535/1485 |
| Curb Weight（Kg）/整备质量 | 2320 |
| rated payload (Kg)/额定载质量 | 3500 |
| G.VW/总重量 | 5320 |
| Max. gradeability(°)/最大爬坡度 | 30% |
| front axle payload/前桥吨位 | 2T |
| Rear axle后桥吨位/Main reduction ratio主减速比 | 3.5T/4.875 |
| Tyre size/轮胎尺寸 | 6+1/6.50R16 |
| Brake system/制动系统 | Hydraulic brake/Air brake |
| Parking brake/驻车制动 | Central drum type |
| gearbox/变速箱 | 5MT |
| Capacity of fuel tank（L）/油箱容积 | 80L |
| battery/ 电池 | 12V |
| Engine model/发动机型号 | JE493ZLQ3A(ISUZU） |
| Displacement/Cilindrad a(cc)排量 | 2771 |
| Power/Potencia(KW)/发动机功率 | 75/3600 |
| Torque/Par(N.m)发动机扭矩 | 240/2000 |
| seat material/座椅材质 | fabric |
| power steering/助力转向 | ● |
| media/媒体 | MP5 with reverse camera |
| A/C空调 | ● |
| power window/电动车窗 | ● |
| Central lock/中控锁 | ● |
